Galvanized BTO-22 Welded Razor Wire Mesh with 75x150mm Aperture Mineral fences
Razor wire flat wrap coils are made of high tensile razor wire, clapped into a flat panel formation.
Installation Forms
-
Flat wrap coils can be used in the following forms:
-
Installed against the existing smooth wire mesh fence;
-
Fitted to the welded mesh fence;
-
Fitted by overlapping the fence mesh;
-
Installed to the brick wall directly.
Advantages:
-
Flat wrap coils will substantially improve the effectiveness of the fence. Installed on this basis, innocent persons are protected from injury by the smooth wire mesh fence while the potential intruders will get frightened back.
-
he flat coils provide a neat but effective barrier when used together with mesh fences.
-
Flat wrap coil installation is particularly simple when it is fitted by overlapping the fence mesh.
-
It provides a high barrier when mounted to the wall.
Installation of flat wrap coil razor wire is simple when it is fitted.
500 mm high flat wrap fitted to our welded mesh fence provides a neat but effective barrier.
Installation of razor wire flat wrap coils is particularly simple when it is fitted by overlapping the fence mesh, shown here.
2 × 900 mm flat wrap installed against an existing smooth wire mesh fence substantially improves the effectiveness of the fence. Installed on this basis, innocent persons are protected from injury by the smooth wire mesh.
Many rolls of razor wire flat wrap coils
Many rolls of razor wire flat wrap coils Razor Wire Flat wrap Specifications - Standard Coil Sizes
| Height | Length | Weight |
| 500 mm
(20 inch) | 15 m
(50 ft.) | 9.5 kg
(21 lbs) |
| 700 mm
(28 inch) | 15 m
(50 ft.) | 13 kg
(29 lbs) |
| 900 mm
(36 inch) | 15 m
(50 ft.) | 14.5 kg
(32 lbs) |
Straight Line Razor Wire is a kind of barbed wire but in the shape of straight line which is usually fixed at the top of the wire mesh fences or walls to prevent intruders and thieves from entering the places. It has features of easy installation, aesthetic appearance and excellent protective performance. Galvanized BTO-22 Welded Razor Wire Mesh is a multi-functional, high security mesh fencing made of straight-blade netting welded together, packaging into a roll form for minerals,prison and so on. Welded Razor Wire Mesh is used in operations to pave the field after the installation of a blade barrier. This product can protect you and your property, and ensures the safety of the protective barriers.
Specification:
Height x Length:1.2m X 6m,1.8m X 6m,2.1m X 6m,2.4m X 6m
Aperture Size:
Square Hole Size:100mmx100mm,150mmx150mm,200mmx200mm.
Diamond Hole Size:75mmx150mm,100mmx200mm,150mmx300mm.
Usage: Mainly serves in protecting of grass boundary, railway, highway and also widely used in military, and industry, agriculture, animal husbandry, dwelling house, also used as fence for cottage as society fence and other private buildings.
Standard specifications are shown in the tables below, special specification are available on requests.
| Model | Panel size(HxL) | Aperture Size |
| BTO-22,CBT-65 | 1.2Mx6M, 1.8Mx6M
2.1Mx6M, 2.4Mx6M | 75mmx150mm,150mmx300mm |
| BTO-22,CBT-65 | 1.2Mx6M, 1.8Mx6M
2.1Mx6M, 2.4Mx6M | 75mmx150mm,150mmx300mm |
| BTO-22,CBT-65 | 1.2Mx6M, 1.8Mx6M
2.1Mx6M, 2.4Mx6M | 75mmx150mm,150mmx300mm |
| BTO-22,CBT-65 | 1.2Mx6M, 1.8Mx6M
2.1Mx6M, 2.4Mx6M | 75mmx150mm,150mmx300mm |
Strict Control of Raw Materials
Processing & Packaging
|
|
BTO-22 Welded Razor Wire Mesh with 75x150mm Aperture Images
|
