STANDARD 7 BAR GATE*1 3/4″ O.D. round tubular steel

Name: STANDARD 7 BAR GATE1 34 OD round tubular steel
Brand: LNF-Farm Gates
Price: 19.66 USD

China STANDARD 7 BAR GATE*1 3/4″ O.D. round tubular steel factory

Brand Name : LNF-Farm Gates

Model Number : Farm Fencing materials

Certification : ISO

Place of Origin : Farm Panels and Gates

MOQ : 100unit

Price : 19.66$-48.68$

Payment Terms : TT

Supply Ability : 10000

Delivery Time : 14 work days

Packaging Details : Pallet

Materials : Q235 steel pre hot dipped galvanized steel pipe

Color : Any Ral Color

Treatment : Hot Dipped Glavanized,Powder Coated

Thickness : 1.2-2.5mm

Type : Weld panels

Warranty : 5 -25 years depand on the treatment

Main Market : Oceania Europea ,Middle East ,USA ,AU etc

Accessoires : U and L lugs

Customized : Available

Sample : Free but pay freight cost

Square pipes : 40*40mm*1.6mm,50*50*1.6m

Round Pipes : 32mm,42mmO.D,1.6mm thick

Oval Pipes : 30*60*1.6mm,40*80*1.6mm

Height : 1.6m high with 5 bars,1.8m

Name : Heavy duty galvanized livestock panel ,cattle panel ,horse pane, ,sheep panels

Stanard Size : 1800x2100,1600mm x 2100mm

Contact Now

STANDARD 7 BAR GATE

Materials: Carbon steel

Corrosion Form: hot-dipped galvanized or paint

Features: It can quickly and easily be installed, without the need to disturb the surface

area by digging holes or laying foundations.

Main markets: Australia, European countries, Canada, America and Asia countries.

Description:

-6ft high with 2.3.4.5.6. bars/rails or 5ft high with 2.3.4.5.6. bars/rails.

Specification :

Specification	Normal size
Height x Length	6ft x 10ft, 6ft x12ft, 6ft x 24ft and so on
pole style	Round pipe or square tube or oval tube
Pole specification	15/8"OD
Package details	In steel pallet or in bulk

STANDARD 7 BAR GATE*1 3/4″ O.D. round tubular steel

50 inches in height
Consist of 1 3/4″ O.D. round tubular steel
7 horizontal bars- Horizontal bars are placed through the brace before welding
Braces are made by using flat steel, then punching holes through the steel, folding the edges, and adding two additional bends to provide stability, strength, and completion of the Z formation
Corners are rounded
Hinges: Top is adjustable; Bottom hinge is welded in place to help prevent twisting and turning
5/8″ x 13″ threaded rod hanger
Welded Heavy Duty Chain and latch
Available in lengths from 4′ to 20′ in 2′ intervals
Available in Green
Available in Red (order only)

Order Chart
Length	Vertical Z Braces	Order#
20′	4	SG207
18′	3	SG187
16′	3	SG167
14′	2	SG147
12′	2	SG127
10′	1	SG107
8′	1	SG87
6′	1	SG67
4′	0	SG47

STANDARD 7 BAR GATE*1 3/4″ O.D. round tubular steel Images
